plastic sheet extruder machinery plastic rattan extruder machinery plastic yarn extruder production line-HANKER
plastic sheet extruder machinery plastic rattan extruder machinery plastic yarn extruder production line plastic sheet extruder machinery plastic rattan extruder machinery plastic yarn extruder production line plastic sheet extruder machinery plastic rattan extruder machinery plastic yarn extruder production line plastic sheet extruder machinery plastic rattan extruder machinery plastic yarn extruder production line plastic sheet extruder machinery plastic rattan extruder machinery plastic yarn extruder production line plastic sheet extruder machinery plastic rattan extruder machinery plastic yarn extruder production line plastic sheet extruder machinery plastic rattan extruder machinery plastic yarn extruder production line

plastic sheet extruder machinery plastic rattan extruder machinery plastic yarn extruder production line

SEND A MESSAGE :

WhatsA pp : +8618030169616 Tel .: +86 18030169616

Email : allen@crtopmachine.com Skype : +8618030169616


  • Item No.:

    CRT-168

  • Product Origin:

    China

  • Shipping Port:

    Xiamen (Or any port in China)

  • Min Order:

    1

  • Lead Time:

    7-10 days

  • Compliance:

    CE

  • Minimum Order Quantity:

    1

  • Operation method:

    fully automatic

  • Screen:

    push button

  • Capacity:

    0.1-5kg

  • Speed:

    15r/min

  • Voltage:

    220/110V Or customize

  • Warranty:

    1 year

  • Dimension(L*W*H):

    0.75m * 0.2m * 0.5m

  • Delivery Time:

    6-8Day

  • Packaging Details:

    Standard export wooden box
contact now
Product Details
The basic performance parameters
1, Capacity: 0.1-5KG / hr
2, Screw rotation speed: max to 15r/min
3, The production line center height: 300mm;
5, Line direction: left and right to close the discharge →
6, The installation area: length×width*height = 0.75m * 0.2m * 0.5m ; weight: about 30KG
7. Motor Power: 250W
8. Voltage: 220V 110V, or customers can specify

Technical Parameters

Model
 SJ-15 SJ-25
 SJ-35
 Click on WhatsApp to query the quotation>>

Production Capacity
 0-5 (kg/h)
Raw Material
 PE/PP/PVC/ PLA/PC/TPU/ABS/NYNONG
Voltage
 Single phase, 220V 60Hz
Main Motor Power
 250W
Heating Power
 1000W
Screw
 Single Screw Extruder
Diameter
 35mm
Screw L/D
 12: 1
Material
 38CrMoAlA
Surface treatment
 Nitrogenization and polished
Inner surface treatment
 Nitrogenization and polished
Max heating temperature
 300℃
The nitride layer thickness
 0.5~0.7 millimeters.
The surface hardness
 HV850~940
Extruder total Power
 940W
Control Type
 Single-phase electronic governor control
Heating control zone
 3


Packing & Delivery
